On-Site Lining

Onsite lining systems use a 1.5mm thick lining material, available in a choice of colours and patterns, which is welded into the swimming pool shell onsite. Onsite lining systems have a much longer life expectancy than standard  factory made liners and can be used for longer at a much higher swimming pool water temperature.

Once the shell of the pool is prepared, or built, and the skimmers, inlets, lights, main drains and linerlock are in place, an underlay is glued to the base and sides of the pool. Then a bead is welded to the top of the side walls. There is an option for adifferent type of fixing whereby PVC coated metal is welded directly onto the metal profile. This system is useful when renovating old pools when its important not to disturb the copng stones.



The Sidewall is then clipped into the linerlock (or welded to the metal profile) and cut to the correct depth. the base of the pool can now be lined and the sidewalls welded to the base.   The material is over-lapped by 50mm and welded by a hot air gun.



Onsite lining system are ideal for renovating and refurbishing pools and also for pools with unusual or complicated shapes.

It has an exceptional stregth. The material, which incorprates a polyester reinforced mesh, is 1.5mm thick which enables it to withstand intensive use and severe knocking from even the most enthusiastic swimmer. It also has a special formular that includes a UV stabilising treatment which can withstand exposure to all extreme weather, retaining its properties year after year.

Guaranteed for ten years, with a life expectancy nearer 15 to 20 years. On-site lining can be used on concrete, cement, render, brick or block, steel or aluminium, timber or fiberglass.

An on-site lined pool can be run at temperatures up to 33°C (91°F) without any detrimental effect on the expected life of the lining. Even at temperatures up to 35°C (95°F) the lining will give many years of service and is still covered by a more limited five year guarantee.

Below are a small selection of the patterns available



The Touch Range

The Touch Range is manufactured in extremely tough 2.00mm material and is the only pool lining to have a natural looking texture incorporated into it.

The patterns are designed to give a natural feel and appearance, giving the sensation of swimming in a natural pool or lagoon whilst never comprimising on the high protectionaspect. The multiple layers of acrylic varnish ensure a finish which will look fantastic for years to come, and will withstand all kinds of punishment endured in a swimming pool environment.

 The 3D embossed Touch range is presented in three different patterns
